ELM327 V1.5 PIC18F25K80 Bluetooth OBD2 Scanner ODB2 Diagnostic Tool Mini ELM 327 V1.5 Auto OBD 2 Car Code Reader for Android

Shipping Time: Shipping cost:
Quantity:
In Stock
Free shipping worldwide
60 Day Returns
View Cart
Guaranteed safe checkout
Product Details
Shipping & Payment
Product Details

Mini ELM327 V1.5 PIC18F25K80 Bluetooth ELM 327 V1.5 Adapter obd2 Scanner OBD 2 OBD2 Car Diagnostic Auto Tool ODB2 Code Reader

Purchase Notes:

1.If you choose Yanwen Econnomic Air Mail,this Shipping wat can not be tracked,please noted,thanks

2.When adapter can not connect to your car,please contact us,we will solve problem for you

3.When you make order,please note to choose you need:1 PCB V1.5/ 2 PCB V1.5 /1 PCB V2.1

4.Support ATAL/ATPPS with 4MHZ Chip

ELM327V1.5Double/Single PCB Compared:

1.Special chip:PIC18F25K80 Chip(V2.1 ELM327 without this chip)

2.Connection method:Bluetooth 2.0

3.Supported systems: Android/PC(Don’t support IOS,if you need,please contact us)Supported systems

4.Hardware version:V1.5

5.Software:Android: ELM327 dentifier/Torgue/Dashcommand/Auto Doctor PC: Scanmaster

6.Features:Support ATAL/ATPPS and 4MHZ Chip, Support 9 Standard OBD2 Protocols, 90% cars can be supported

Purchase Notes:All products are sold without CD. If you need software, please download in the mobile APPstore or scan the packaged QR code, or contact the buyer for download link,and V2.1 Version some car can’t support

Super Mini ELM327 Bluetooth Functions:

1: Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).

2: Clear trouble codes and turn off the MIL ( “Check Engine” light)

3: Display current sensor data, including:

4: Engine RPM

5: Calculated Load Value

6: Coolant Temperature

7: Fuel System Status

8: Vehicle Speed

9: Short Term Fuel Trim

10: Long Term Fuel Trim

11: Intake Manifold Pressure

12: Timing Advance

13: Intake Air Temperature

14: Air Flow Rate

15: Absolute Throttle Position

16: Oxygen sensor voltages / associated short term fuel trims

17: Fuel System status

18: Fuel Pressure

19: Many others

Connection Operation:

①-Open the setting of your Android , and search Bluetoothfrom ELM327 : OBDII ,then input password 1234

②-1.Open your Torque—setting

2.OBD2 Adapter Settings

3.Connection Type—choose Bluetooth—back

4.Choose Bluetooth DEVICE—OBDII[00: 1 D: A5: 02: 6F: 03]

5. Select Quit, then reopen the software and waiting for connection

Supported protocols:

1.SAE J1850 PWM (41.6Kbaud)

2.SAE J1850 VPW (10.4Kbaud)

3.ISO9141-2 (5 baud init, 10.4Kbaud)

4.ISO14230-4 KWP (5 baud init, 10.4 Kbaud)

5.ISO14230-4 KWP (fast init, 10.4 Kbaud)

6.ISO15765-4 CAN (11bit ID, 500 Kbaud)

7.ISO15765-4 CAN (29bit ID, 500 Kbaud)

8.ISO15765-4 CAN (11bit ID, 250 Kbaud)

9.ISO15765-4 CAN (29bit ID, 250 Kbaud)

Support ATAL/ATPPS etc.

Software Address:

Android: ELM327 dentifier/Torgue/Dashcommand/Auto Doctor

PC: Scanmaster(www.elm327.com)

Product Display:

Old version ELM327double PCB boardwith PIC18F25K80(Normal Packet):

New OBDII Elm327 v1.5Single PCBPIC18F25K80(Carton package):

Packing listing: 1pc X Super MINI ELM327 V1.5/V2.1 Bluetooth Diagnostic Interface Normal package ELM327 V1.5:   Carton package ELM327 V1.5:
